Specifiche Tecniche:
Electrical
- Contact Resistance ≤ 10 mohm
- Insulation Resistance ≥ 200 Mohm(Initial)
- Dielectric Strength 0.5 KVDC 50HZ
Mechanical
- Lifetime > 5,000 Mating Cycles
- Insertion and Withdrawal Force 5 - 40 N
- Cable O.D. max. 4.5 mm for standard outlet
- max 6.4 mm for large outlet ( * L）
- max 8.5 mm for large outlet ( * LL）
Material
- Plug finger Brass
- Sleeve Zinc
- Retainer ring PA66+30%GF
- Soldering Contact Phosphor Bronze
- Cable Clamp Steel
- Insulation PP
- Housing Zinc
- Plug finger plating Nickel
- Sleeve plating Nickel
- Soldering Contact plating Tin
- Cable Clamp plating Tin
- Housing plating Nickel
