Specifiche Tecniche:
Technical characteristics
- Lenght: 20 m
- Signal type: HDMI 2.0
- Input connector type: HDMI Type A male
- Output connector type: HDMI Type A male
- Connector fastening type: "C-LOCK" type HDMI connector provide
- Connector gold plating: gold-plated copper shell
- Connector structure: zinc alloy mold
- Power from connector (TX): not supported
- Cable power supply (RX): not supported
- Power: 250 mW
- Connector dimensions: HDMI Type A male, 55.2 x 20 x 12 mm
- Plug & Play: yes
- In-wall installation: not supported
- Fiber type: multi-mode OM3-300 x 4
- Fiber wavelength: 850 - 1300 nm
- Copper wire material: 7 multi-strand tinned copper wires
- Copper wire specification: 24AWG1, 26AWG1, 28AWG3, 30AWG2
- Cable structure: optical fiber + inner jacket + Kevlar + copper wire + aluminum foil + armored tube + outer jacket
- Cable diameter: 5.8 mm
- Jacket color: black
- Jacket material: matt frosted TPU
- Spiral tube diameter: 2.88 mm ± 0.1 mm
- Spiral tube color: silver
- Spiral tube material: stainless steel
- Packing dimensions: 240 x 230 x 75 mm
- EDID: pass-through
- DDC: yes
- HDMI audio: yes
- 3D: yes
- CEC: yes
- ARC: yes
- HDCP: HDCP 2.3
- HDR: yes
- XvYCC color space: yes
- Optical module: 4 x 10G multi-mode optical
- Technical characteristics: photoelectric conversion technology
- Optical module lifetime: 100,000 hours
- Resolution: 3840 x 2160 @ 60 Hz
- Clock bandwidth: 600 MHz x 3
- Transmission rate: 18 Gbps
- Reclocking chip: support above 30 m
- Pixel reclocking: yes
- ESD protection: yes
- Hot swap: yes
- Delay: zero frame delay
- Compression: none
- Sampling rate: 8 - 16 bit within the bandwidth range
- Sampling ratio: RGB 4:4:4, YUV 4:4:4, YUV 4:2:2, YUV 4:2:0
- Anti-jamming: yes
- Tensile strength: ≤ 700N
- Compressive strength: 2000 N/10 cm
- Minimum bending radius: dynamic > 10D; Static > 20D (*D is the outer diameter of the cable)
- Operating temperature: -30 to 80 ℃
