Specifiche Tecniche:
Technical characteristics
- Lenght: 100 m
- Connector type: RJ45 UTP
- Cable type: CAT6 UTP
- Environmental information: RoHS 2.0 compliant
- Connector size: 45.7 x 17.69 x 13.8 mm
- Connector components: SR＋RJ45 plug＋boot
- RJ45 connector: one-piece single-row modular plug (PA66)
- Connector color: black
- Gold plate thickness: 1 μm - 50 μm
- Latch tab material: PA66
- Boot: injection molded boot
- Structure: conductor + inner sheath + outer jacket
- Conductor gauge: 24AWG
- Conductor size: 7/0.20 ±0.008 mm x 8
- Conductor material: multi-strand oxygen-free copper
- Insulation material: HDPE
- Insulation outer diameter: 0.95 - 0.97 mm
- Insulation average thickness: 0.17 mm
- Insulation minimum thickness: 0.15 mm
- Insulation color code: 1P: blue & white / blue; 2P: orange & white / orange; 3P: green & white / green; 4P: brown & white / brown
- Core wire direction: s
- Core wire lay length: < 30 mm
- Cable direction: s
- Cable lay length: ≤ 120 mm
- Cable meter mark: waterproof text
- Conductor resistance: 3 ohm max.
- Insulation resistance: 10 Mohm min., 300 VDC 0.01 s
- Withstand voltage: 300 VDC 0.1 s
- Delay difference: ≤ 45 ns
- Frequency: 250 MHz
- Impedance: 100 ±15 ohm
- Testing: pass Fluke
- Insulation elongation: ≥ 300%
- Insulation tensile: ≥ 16 Mpa
- Jacket outer diameter: 6.4 ±0.15 mm
- Outer jacket material: composite material
- Jacket elongation: ≥ 100%
- Jacket tensile: ≥ 12.5 Mpa
- Operating temperature: -20 to 60 ℃
- Operating voltage: 30 V
