Specifiche Tecniche:
Features & Benefits
- Current rating 30 A rms
- Glass reinforced materials make it extremely robust and dependable
- Precise keyway for secure mating
- Accurate twist lock latching system
- Metal insert in locking area
- Airtight design - optimized for speaker applications
Product
- Title NL2MP
- Gender male
Electrical
- Contact resistance ≤ 3 mΩ (after lifetime)
- Dielectric strength 4 kVdc (peak)
- Insulation resistance > 1 GΩ (after dampheat)
- Rated current per contact 30 A rms continuous
- Rated current per contact 40 A audiosignal, duty cycle 50 %
- Rated voltage 250 V ac
- Attention speakON is NOT to be used as an AC mains or power supply connector!
Mechanical
- Lifetime > 5000 mating cycles
- Wiresize
- Locking device Quick Lock
- Chassis shape D
- Layout standard hole position, thru holes
Material
- Contact plating 4 µm Ag
- Contacts Bronze (CuSn6)
- Shell Polyamide (PA 6 30 % GR) black
Environmental
- Temperature range -30 °C to +80 °C
