Specifiche Tecniche:
Technical characteristics
Electrical
- Contact resistance: ≤ 10 mohm
- Insulation resistance: > 200 Mohm (initial)
- Dielectric strength: 500 VDC 50 Hz
Mechanical
- Insertion and withdrawal force: 5 - 40 N
- Lifetime: > 5000 mating cycles
Material
- Tip: brass
- Bushing: PA66 + 30% GF
- Insert: brass
- Sleeve: brass
- Insulation: PVC
- Threaded: nut brass
- Insulator: PA66 + 30% GF
- Housing: zinc
- Soldering: contact brass
- Cable clamp: steel
- Tip: nickel plating
- Insert: nickel plating
- Sleeve: nickel plating
- Threaded nut: nickel plating
- Housing: nickel plating
- Soldering contact: tin and cer
- Cable clamp: tin and cer
