Specifiche Tecniche:
Technical characteristics
|
Type |
AM / FM tuner / MP3 CD & MP3 player |
|
Inputs |
USB port - SD/MMC support |
|
Outputs |
2 x 2 RCA (L/R) |
|
Power supply |
230 VAC 50 Hz |
|
Frequency response |
20 - 20,000 Hz ±2 dB |
|
Distortion |
≤ 0.1% @ 1 kHz |
|
Channels separation |
> 65 dB @ 1 kHz |
|
Dynamic range |
75 dB
|
|
S/N ratio |
> 85 dB |
|
Output level |
0.775 V |
|
Tuner section |
|
|
Frequency range |
FM 87.5 - 108 MHz / AM 522 - 1620 kHz |
|
Antenna inputs |
AM Antenna / FM Antenna 75 ohm |
|
Sensitivity |
FM: ≤ 10 µA, AM: ≤ 100 µA |
|
Station memories |
99 |
|
Dimensions (W x D x H) |
484 x 215 x 44 mm (19" 1U) |
|
Weight |
3.7 kg |
