Specifiche Tecniche:
- 4 channel mixer, 2 microphones, 2 stereo, 1 aux and USB port
- 2 x microphone inputs via XLR plugs
- 2 x 6.35 mm jack balanced line input
- 2 x unbalanced stereo inputs on RCA and 3.5 mm jack
- 2-band equalizer on MIC/line and stereo channels
- Gain control for each channel
- AUX level setting on each channel
- Balanced MAIN output on 6.35 mm jack
- Unbalanced Record output via RCA plugs
- Balanced AUX output on 6.35 mm jack
- Monitoring output via 6.35 mm stereo jack
- 1 USB port for connecting a computer
- LED VU-meter for MAIN output
| MIC input | 2 |
| Stereo input | 2 |
| Aux | 1 |
| Stereo L/R output | 2 |
| USB port full duplex | 1 |
| Phantom power | +48 VDC |
| Gain | 65 dB (MIC main output) |
| MIC CH. EQ ±15 dB | HI: 12 kHz, LO: 80 Hz |
| LINE CH. EQ ±15 dB | HI: 12 kHz, LO: 80 Hz |
| Frequency response | (20 Hz -20 kHz) ±1 dB |
| Maximum output level | +20 dBu |
| Meter | 4 segments (-20 dB to CLIP) |
| Distortion | ≤0.08% (20 Hz -20 kHz) |
| Power supply | 12 VDC external adaptor |
| Weight | 0.78 kg |
| Dimension (W x D x H) | 220 x 160 x 68 mm |
